UPS Power Not Redundant 10296 1 1
Power Module Failure 10298 1 1
Battery Module Failure 10299 1 1
Power Module Warning 10300 1 1
Battery Module Warning 10301 1 1
Data Point
Input
Register
Holding
Register
# of
Reg. Scale Notes/ Units
Number Of Input Lines 30004 40004 1 1 Bits 12 - 15
Number Of Bypass Lines 30004 40004 1 1 Bits 4 - 7
Number Of Output Lines 30004 40004 1 1 Bits 8 - 11
Number Of Power Mod. 30010 40010 1 1
Number Of Battery Modules
Installed
30011 40011 1 1
Device Maximum Frame
Capacity
30023 40023 2 1
Device System Capacity 30025 40025 2 1 VA
Nominal Input Voltage 30027 40027 1 1 V
Nominal Output Voltage 30028 40028 1 1 V
Nominal Static Bypass
Switch Voltage
30029 40029 1 1 V
Nominal Input Frequency 30031 40031 1 10 Hz
Nominal Output Frequency 30032 40032 1 10 Hz
Nominal Power Factor 30033 40033 1 100
Nominal Battery Voltage 30034 40034 1 1 V
Auto Restart Delay 30051 40051 1 1 seconds
Device Auto Restart
Percent Setpt
30052 40052 1 1 %
Device Low Battery Time 30053 40053 1 1 min
Next Battery Auto Test
Time
30057 40057 1 1 minutes
Overload Alarm Limit 30067 40067 2 1 VA
Minimum Redundant Power
Modules
30074 40074 1 1
Load (Apparent Power) 30102 2 1 VA
Load (Real Power) 30104 2 1 W
Load / Capacity 30106 1 1 %
Input Frequency 30107 1 10 Hz
Output Frequency 30108 1 10 Hz
Bypass Frequency 30109 1 10 Hz
Battery Charge Status 30112 1
1 - 100% Charged
2 - Less than 100% Charged
3 - Charging
4 - Discharging
5 - Float Charging
6 - Equalize Charging
Battery Voltage 30113 1 1 V
Battery Time Remaining 30115 1 1 min
