REV. 5

7/6/2007

Liebert Monitoring Group –Development

4

Liebert Nfinity

Supported Modbus Points

Data Point

Status

Coil

# of

Reg. Scale Notes/ Units

Automatic Battery Test
Enabled

10003

3

1

1

Battery Charger On

10044

1

1

Inverter Ready

10047

1

1

Power Factor Correction
State 10050

1

1

Load On Inverter

10073

1

1

Bypass Active

10074

1

1

Replace Battery

10081

1

1

Battery Under Test

10082

1

1

Load On Battery

10128

1

1

Load On Bypass

10129

1

1

Load On Manual Bypass

10132

1

1

Load Transferred To
Bypass Due To UPS Fault

10134

1 1

Transfer Inhibit

10146

1

1

Output Off Pending

10151

1

1

Low Battery - Shutdown
Imminent

10152

1

1

Output Overload

10154

1

1

UPS Overload

10155

1

1

Output Off

10158

1

1

Check Air Filter - Replace

10170

1

1

Transformer Over
Temperature

10178

1 1

Input Power Supply Fail

10186

1

1

Internal Device
Communication Failure

10284

1

1

Device Active Alarm

10290

1

1

Main Control Warning

10291

1

1

Redundant Control Warning 10292

1

1

Control Module Failure

10293

1

1

Redundant Control Module
Failed

10294

1

1

User Interface Module
Failed 10295

1

1
