REV. 5 7/6/2007
Liebert Monitoring Group –Development
23
Input Current L2 30204 1 1 A
Input Voltage L3 30253 1 1 V
Input Current L3 30254 1 1 A
Liebert UPS Series 600
Supported Modbus Points
Data Point Status Coil # of
Reg.
Scale Notes / Units
Battery Charger On 10044 1 1
Battery Charge
Compensation 10046 1 1
Inverter Ready 10047 1 1
Auto Retransfer
Primed 10049 1 1
Load On Inverter 10073 1 1
Load On Bypass 10074 1 1
Buck On 10076 1 1
Battery data Buffer Full 10084 1 1
Shutdown Reason –
Hardware 10096 1 1
Load On Battery 10128 1 1
Manual Reset Transfer 10130 1 1
Load On Bypass
Permanent 10133 1 1
Load On Bypass-UPS
fault 10134 1 1
Battery Switch Open 10136 1 1
Input Switch Open 10137 1 1
Output Switch open 10138 1 1
Emergency Load
Transfer to Inverter 10145 1 1
Transfer inhibited –
Asynchronous
Sources 10146 1 1
Transfer inhibited –
over predefined limit 10147 1 1
SBS SCR Open 10149 1 1
SBS SCR Short 10150 1 1
Low Battery -
Shutdown Imminent 10152 1 1
Output Overload 10154 1 1
Over Temperature
Warning 10171 1 1
Battery Over
Temperature CB Trip 10172 1 1
Input Power Supply
Fail 10186 1 1
Input Under Voltage 10188 1 1
Input Brown Out 10189 1 1
