RIGOL
MSO1000Z/DS1000Z User’s Guide
14-3
4. Setups
Save the settings of the oscilloscope to internal or external memory in "*.stp"
format. The stored settings can be recalled.
5. CSV
Save the waveform data displayed on the screen or of the specified channels in
external memory in a single "*.csv" file. You can specify the file name and the
saving directory and save the corresponding parameter file (*.txt) under the
same directory using the same file name. This parameter file is the same as the
"Parameters" function. The recall of CSV and parameter files is not supported.
After selecting this type:
Press DataSrc to select "Screen" or "Memory". After selecting "Memory", press
Channel to select the desired channel (
Note:
Only channels currently enabled
can be selected).
Press Param to enable or disable the parameter save function.
Press Sequence to choose whether to add sequence numbers for the waveform
points in the CSV file. You can select "ON" or "OFF" and the default is "ON"
(namely add the sequence number).
6. Parameters
Save the parameters of the screen waveform to external memory in "*.txt"
format. The parameter storage contain the system information (such as the
software and hardware version numbers, time, date, etc) and the current
related setting information of the instrument (such as vertical, horizontal, trigger
and channel switching state, etc).
