Chapter 13 Signal Source RIGOL
MSO1000Z/DS1000Z User’s Guide 13-1
Chapter 13 Signal Source
MSO1000Z/DS1000Z combines signal generator and oscilloscope in one instrument
by providing a built-in dual-channel, 25MHz signal generator, thus providing
convenience for engineers who need to use the signal generator and oscilloscope at
the same time. This chapter introduces how to use the built-in signal generator. As
the functions and setting methods of source 1 and source 2 are the same, this
chapter takes Source 1 for illustration.
Press Source to enter the signal generator control menu.
 Press Output to enable or disable the signal output. When it is enabled, the
[Source1] connector at the rear panel outputs a signal according to the current
setting.
 Press Src1Conf to set the signal type and the signal parameters.
 Press StatusDisp to view the parameter settings of SOURCE1 and SOURCE2,
such as the frequency, amplitude, offset, phase, modulation type and
modulation frequency, etc.
 Press RecoveryCalls to set the output signal type and parameters to be
recalled when the oscilloscope is powered on again after power-off. You can
select "Last" or "Default".
 Pressing Factory can restore the default settings of the signal source
separately.
Note: The function of Source  Output is the same with that of Source 
Src1Conf  Output.
The contents of this chapter:
 To Output Basic Waveform
 To Output Built-in Waveform
 To Output Arbitrary Waveform
 Modulation
