Vigor3300 Series User’s Guide 18
End IP Assign the end IP address of the IP pool that DHCP sever can
use for clients in LAN.
Primary DNS Type the IP address for primary DNS.
When you finished the above required settings, please click Finish. A system reboot page will
appear. Click Apply to activate the DHCP mode configuration.
2 2 . . 2 2 . . 4 4 P P P P P P o o E E
This mode is used for most of DSL modem users. All local users can share one PPPoE
connection to access the Internet. Your service provider will give you the user name, password,
and authentication mode for PPPoE settings.
If your ISP provides you the PPPoE (Point-to-Point Protocol over Ethernet) connection,
please select PPPoE for this router to get the following page. Enter the username and
password provided by your ISP on the web page.
User Name Assign a specific valid user name provided by the ISP.
Password Assign a valid password provided by the ISP.
Authentication Select PAP or CHAP protocol for PPP authentication. The
default value is PAP.
Service Name Assign a service name required from ISP service.
After setting up the WAN interface, the user can click Next to setup the LAN interface
continuously.
