RGB 168xi xi xi xi xi • Installation and Operation
Installation and Operation, cont’d
2-4
5 Buffered local monitor output 15-pin HD female
connector
— This allows output to a local monitor.
Set the ID PIN DIP switches to On if this connector is
not used.
6 Horizontal shift control knob — This control adjusts
the horizontal centering of the remote output
display.
The horizontal shift control has no mechanical limits
to rotation. When the minimum or maximum limit
of the control is reached, the picture ceases to move
on screen, and the MIN/MAX indicator LED lights
red.
If the DDSP DIP switch is set to On, the horizontal
shift control is disabled.
7 MIN/MAX indicator LED — This LED lights red
whenever the lower or upper limits of the horizontal
or vertical shift controls are reached.
8 Optional architectural adapter plates — Up to four
adapter plates for pass-through audio/video
connections can be attached at one time to the
interface. See the “Installing Adapter Plates” section
in this chapter for installation instructions.
9 AC power output connector — An unswitched
standard IEC AC power connector allows you to
connect a peripheral device that requires power. This
feature is not available in Europe (RGB 168xi Int).
