Appendix B - Minimum Clearance SMA Solar Technology AG
84 SC125_560HE-IEN083220 Installation Guide
* Distance to a closed building wall
** Distance to a building wall with air grills
SC 250HE
air outlet (to the rear) 600*/
100**
100 200 600*/
50**
1100
SC 250HE
air outlet (above) 100 100 400 10 1100
SC 350 Standard 100** 100 400 50** 1100
SC 350HE 100** 100 400 50** 1100
SC 500HE 100** 100 400 50** 1100
SC 560HE 100** 100 400 50** 1100
Sunny Central D (mm) E (mm) F (mm) G (mm) H (mm)
