Technical Data SMA Solar Technology AG
64 SB12-17-IA-en-52 Installation Guide
Mechanical data
Climatic Conditions
* according to DIN EN 50178:1998-04, installation type C, class 4K4H
** according to DIN EN 50178:1998-04, transport type E, class 2K3
Features
General data
Protective equipment
Communication Interfaces
Width x height x depth 440 mm x 339 mm x 214 mm
Weight 23 kg
Extended temperature range * − 25 °C … +60 °C
Extended humidity range * 0 % … 100 %
Extended air pressure range * 79.5 kPa … 106 kPa
Temperature range ** − 25 °C … +70 °C
Operation temperature range − 25 °C … +60 °C
Maximum operating altitude above mean sea
level 2 000 m
Topology LF transformer
Protection rating according to DIN EN 60529 IP65
Protection class I
Noise emission (typical) ≤ 41 dB(A)
All-pole DC switch-disconnector Electronic Solar Switch,
DC plug system SUNCLIX
DC overvoltage protection Thermally monitored varistors
Personal protection (R
iso
> 1 M Ω ) Insulation monitoring
Pole confusion protection Short circuit diode
AC short circuit protection Current control
All-pole AC disconnection unit Automatic disconnection device SMA Grid
Guard 2.1, double design
Bluetooth ®
Wireless Technology Optional
Radio Optional
RS485, galvanically isolated Optional
