HEIDENHAIN TNC 640 401
16.1 F
undamentals
Characteristics common to all touch probe
cycles for datum setting
Datum point and touch probe axis
From the touch probe axis that you have defined in the measuring
program the TNC determines the working plane for the datum:
415 DATUM INSIDE CORNER
Measuring two lines from the inside of a
corner, and defining the intersection as
datum Page 431
416 DATUM CIRCLE CENTER (2nd soft-
key row) Measuring any three holes on a
bolt hole circle, and defining the bolt-
hole center as datum Page 435
417 DATUM IN TS AXIS (2nd soft-key
row) Measuring any position in the touch
probe axis and defining it as datum Page 439
418 DATUM FROM 4 HOLES (2nd soft-
key row) Measuring 4 holes crosswise
and defining the intersection of the lines
between them as datum Page 441
419 DATUM IN ONE AXIS (2nd soft-key
row) Measuring any position in any axis
and defining it as datum Page 445
Cycle Soft key Page
You can also run the Touch Probe Cycles 408 to 419 during
an active basic rotation.
The tilting the working plane function is not permitted in
combination with Cycles 408 to 419.
Active touch probe axis Datum setting in
Z X and Y
Y Z and X
X Y and Z
