II - 5 Measured Value Output
Examples of character output at the data
interface
A PC can be used to retrieve values from ND 522/523. In all three
examples, measured value output is started with Ctrl B (sent over
USB interface). Ctrl B will transmit the currently displayed values in
either Incremental, or Absolute mode, whichever is currently visible.
Example 1: Linear axis with radius display X = + 41.29 mm
1 Coordinate axis
2 Equal sign
3 +/– sign
4 2 to 7 places before the decimal point
5 Decimal point
6 1 to 6 places after the decimal point
7 Unit: blank space for mm, “ for inches
8 Absolute display:
R
for radius, D for diameter
Distance-to-go display:
r
for radius, d for diameter
9 Carriage return
10 Blank line (Line Feed)
X
=
+
4 1
.
2 9
R
1
2
3
4
5
6
7
8
9
10
