ND 522/523 49
I -
3
Milling
Specific
Oper
ations
Linear Pattern
Information required:
 Linear pattern type (array, or frame)
 First hole (1st hole of the pattern)
 Holes per row (number of holes in each row of pattern)
 Hole spacing (the spacing, or offset between each hole in the row)
 Angle (the angle, or rotation of the pattern)
 Depth (the target depth for drilling in the tool axis)
 Number of rows (number of rows in the pattern)
 Row spacing (the spacing between each row of the pattern)
