196
MAINTENANCE
M
ainte
nance
Turn Signal Bulb Replacement (Front)
To replace a front turn signal bulb:
1. Remove the windshield trim panel (page 184).
2. IMPORTANT: Disconnect the wire harness from
socket BEFORE removing socket from the lens.
Lift the lock tab on the connector and push
connector off of the socket.
3. Rotate the bulb socket counter-clockwise 1/4
turn and remove the socket with bulb.
4. Pull out the old bulb and install the new.
5. Install the socket by engaging in the socket
holder and rotating 1/4 turn clockwise.
6. Connect the wire harness. Be sure it snaps
securely into place over the connector lock tab.
NOTE: Running light (innermost bulb) replacement is the
same as the turn signal bulb, with one exception:
leave wire harness attached to bulb socket when
removing socket from lens.
Remove harness connector from bulb
socket BEFORE rotating socket to remove
IMPORTANT!
it from the lens.
