July 28, 2008 K2 Media Client Service Manual 131
CPU motherboard replacement
Remove Type I motherboard
Remove
13 screws 2
RS-422
boards
DVD
drive
Power
12 volt
power Standby
switch Front USB
(connects
to SCSI
interface
board)
Disconnect
cables 1
1 2 3
Verify position of
video jumper
(Pins 2 & 3)
Refer to procedures for individual FRUs for cabling detail
Lift out 3
PCI slot
Jumper
(JP4)
Continue with step on next illustration 2
