108 K2 Media Client Service Manual July 28, 2008
Chapter 5 Removing and replacing FRUs
Internal Parts Removal
The sections that follow show how to remove internal parts from the K2 Media Client.
• “Top cover removal” on page 109
• “SCSI interface board removal” on page 110
• “Removable media drive removal” on page 111
• “Codec board removal” on page 112
• “Mezzanine board removal” on page 114
• “RTP board removal” on page 115
• “Rear card guide removal” on page 116
• “SCSI backplane removal” on page 117
• “RS-422 adapter removal” on page 119
• “Graphics board removal” on page 121
• “Dual Ethernet adapter removal” on page 122
• “SCSI controller adapter removal” on page 123
• “XLR board removal” on page 124
• “Center support bracket removal” on page 125
• “CPU motherboard replacement” on page 126
CAUTION: To avoid possible damage to circuit boards and other
sensitive parts, turn off the K2 Media Client and disconnect AC power
before opening the top cover or removing any internal parts.
!
