106 K2 Media Client Service Manual July 28, 2008
Chapter 5 Removing and replacing FRUs
Front panel removal
To remove the front panel, first remove the fan module, then proceed as illustrated.
You must remove the front panel before removing the SCSI interface board.
Remove screws 1
Slide panel
straight out 2
