Alinco DJ-S17 User Manual
Page 63
11.Specifications
11
63
11
General
<
DJ-S47
>
Frequency range
E:
TX430~439.995MHz
* 430~439.995MHz
RX430~439.995MHz
* 430~439.995MHz
* Guaranteed range per specifications
Modulation:
F3E (FM)
Frequency step:
5, 10, 12.5, 15, 20, 25, 30kHz step
Memory channel:
200 channels + 1 call channel + 1 Repeater-Access
function memory
Ant. impedance:
50
Ω unbalanced
Frequency stability:
±2.5ppm
Mic. impedance:
2k
Ω
Supply voltage:
DC 7.0~16.0V (EXT DC-IN)
Current consumption:
1.7A (typical) Transmit high at 5W
250mA (typical) Receive at 500mW
80mA (typical) Standby
27mA (typical) Battery save on
Temperature range:
External DC:
-10
°C~+60°C (+14°F~+140°F)
Battery packs: -10
°C~+45°C (+14°F~+113°F)
Ground:
Negative ground
Dimension:
58(W)x110(H)x36.4(D)mm
(2.28"(W)x4.33"(H)x1.43"(D))
(with EBP-65)
Weight:
Approx. 280g (9.9oz)
(with EBP-65)
Sub audible Tone (CTCSS):
encoder/decoder installed (39 tones)
Sub audible Tone (DCS):
encoder/decoder installed (104 codes)
■
