2.Accessories
2
18
2.1.6 Dry Cell Case (optional)
An EDH-34 is available for operation with using AA cells.
Lift up the catches on the top of the case to
remove the cover.
Place 6 AA cells, then close the cover in order of
then . Be sure that the cover is securely closed.
Use high-performance AA cells such as Alkaline or
Oxyride cells.
③
②
①
Caution About Handling Dry Cell Case:
• This dry cell case isn't water-proof.
• Be extra-cautious to the polarity of the cells (+)/(-). Misplacing cells may
result in leak, fire or explosion.
• Use new batteries of the same type and brand when placing them.
• Use of rechargeable cells is prohibited and the manufacturer declines any
responsibilities for damages/injuries that may cause to the users and their properties.
• It is recommended to clean the battery contacting terminals with a clean
dry cloth from time to time.
• Risk of explosion if batteries are replaced by an incorrect type.
• Batteries are recyclable. Please check the local rules for proper
recycle/disposal in your area.
Caution About Battery Charge Function:
The battery charge function is on by default. With this function on and the dry
cells installed, connecting the provided EDC-147/148 AC adapter or an optional
external power supply(stabilized power supply, cigarette lighter cable, etc.) to
the DC-jack on the unit may send current through the dry cells, resulting in
battery leak, heat or explosion. Referring to "Menu 18 Battery Charge Function"
on page 46, be sure to set this function off (select CHG-OF) when the unit is
equipped with the dry cells. However, there is no danger even if CHG-ON is
selected as long as no external power supply is connected to the unit.
