Alinco DJ-S17 - Manual (Page 57)

10.Maintenance and Reference
10
57
5. After charging time is elapsed (page 54), remove the battery pack from the basket.
The red indicator stays turned on as long as the pack is mounted on the basket
regardless of the charging status.
Specifications
*The charging time may vary depending on the condition of the battery pack and the
temperature of the environment.
Charging with the EDC-144 (Quick Charger)
Please make sure that following items are included in the package
• EDC-144E: EDC-144 basket, EDC-151 adapter (AC 230V), insulation sheet
• EDC-144UK: EDC-144 basket, EDC-152 adapter (AC 230V), insulation sheet
• EDC-144R: EDC-144 basket, connection cable, insulation sheet, 2 screws,
connective stay
1. Connect the AC adapter plug to the DC-IN jack on
the back of the basket.
*The design of the AC adapter may vary
depending on the models.
2. Connect the adapter to an outlet.
■
NOTE:
Refer to page 59 for information about how to charge the battery using
addtional baskets.
Caution
Before using them for the first time, attach the insulation sheet to cover the
screw-terminals to avoid short-circuiting. Please refer to page 60 for instruction.
