9.Cloning and Packet Operation
9
48
9. Cloning and Packet Operation
The memory data and customized operational parameters can be transferred from a
Master unit to other DJ-S17/DJ-S47 (Slave units).
9.1.1 Cable Connection
• Make sure that both units are turned off before connecting the cable.
• Connect the Microphone/Speaker jack on the Master unit with the Slave unit using
an optional clone cable (EDS-11) as shown below, then turn on both units.
9.1.2 Master/Slave Units
Press the PTT key three times while holding down
the MONI key.
"CLONE" is displayed on the LCD, and both units
enter the Clone mode.
To the MIC/SP jack on the Master unit
* Be sure to securely screw the plug all the way down to the bottom of the jack.
To the MIC/SP jack on the Slave unit
Cloning
9.1
