7.3.3
0x605B Shutdown_option_code
This object is used to control what action is performed if there is a transition from the
Operation Enabled state to the Ready To Switch On state.
7.3.4
0x605C Disable_operation_option_code
Disable drive function (switch-off the drive power stage).
This object is used to control what action is performed if there is a transition from the
‘Operation Enabled’ state to the ‘Switched On’ state.
7.3.5
0x605E Fault_reaction_option_code
This object is used to control what action is performed when a fault is detected. This
object is ignored if the drive is tripped.
Table 7.11 Shutdown_option_code
0x605B
Shutdown_option_code
Access: RW
Range: 0 to 1
Size: Unsigned 16
Unit: N/A
Default:
N/A
Description:
Used to control what action is performed if there is a transition from the Operation Enabled
state to the Ready To Switch On state.
Table 7.12 Shutdown_option_code values
Value
Definition
0
Disable drive function (switch-off the drive power stage)
1
Slow down with slow down ramp; disable the drive function
Table 7.13 Disabled_operation_option_code
0x605C
Disable_operation_option_code
Access: RW
Range: 0 to 1
Size: Unsigned 16
Unit: N/A
Default:
N/A
Description:
This object is used to control what action is performed if there is a transition from the
Operation Enabled state to the Switched On state.
Table 7.14 Disable_operation_option_code values
Value
Definition
0
Disable drive function (switch-off the drive power stage)
1
Slow down with slow down ramp; disable the drive function
Table 7.15 Fault_reaction_option_code
0x605E
Fault_reaction_option_code
Access: RW
Range: 0 to 2
Size: Unsigned 16
Unit: N/A
Default:
N/A
Description:
This object is used to control what action is performed when a fault is detected.
Table 7.16 Fault_reaction_option_code values
Value
Definition
0
Disable drive function, motor is free to rotate
1
Slow down on slow down ramp
2
Slow down on quick stop ramp
