22
SM-EtherCAT User Guide
www.controltechniques.com Issue Number: 2
Table 6.8 RxPDO mapping 2
0x1601 Receive PDO mapping 2
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 2
Description: The number of mapped objects in this PDO.
Sub-index 1: 1st mapped object
Access: RW Range: 0 to 0xFFFFFFFF Size: 4 bytes Unit: N/A
Default: 0x60400010 - the DSP-402 control word (0x6040)
Description: A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW Range: 0 to 0xFFFFFFFF Size: 4 bytes Unit: N/A
Default: 0x60600008 - the DSP-402 modes of operation object (0x6060)
Description: A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Table 6.9 RxPDO mapping 6
0x1605 Receive PDO mapping 6
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 2
Description: The number of mapped objects in this PDO.
Sub-index 1: 1st mapped object
Access: RW Range: 0 to 0xFFFFFFFF Size: 4 bytes Unit: N/A
Default: 0x60400010 - the DSP-402 control word (0x6040)
Description: A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW Range: 0 to 0xFFFFFFFF Size: 4 bytes Unit: N/A
Default: 0x60600008 - the DSP-402 modes of operation object (0x6060)
Description: A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-bit parameter would have a length
of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
