64
TRI TOOL INC.
92-1197 : Rev. 131230
HD, ELECTRIC DRIVE KIT, 115V & 230V
MOTOR SPECIFICATIONS
Dual Range, Variable Speed
Voltage Input 115 VAC, 40-60 Hz, 2300 Watt rated supply
230 VAC, 40-60 Hz, 2300 Watt rated supply
Power requirements 20 amp
No load rpm 60 - 140 rpm Intermittent non-continuous
uses
MATERIAL CUTTING CAPACITIES INTERMITTENT NON-CONTINUOUS USE
Note: Capacity exceeds the maximum wall thickness for small pipe sizes
Note: Same Range As The Air Motor
Severing with standard procedures
.80" (20.3 mm) wall
Severing with Special procedures 1.50" (38.1 mm) wall
Severing with Single beveling .80" (20.3 mm) wall
Severing with Double beveling .40" (10.2 mm) wall
