49
Model 604SB thru 612SB, Clamshells
92-1197 : Rev. 131230
Parts List, Model 606SB Clamshell Sub-Assy (Ref. P/N 02-2253)
Item Part
No. No. Description Qty
1. 19-0204 HOUSING, MAIN 1 SET
2. 24-0366 PLATE, BEARING BACKING 8
3. 24-0365 PLATE, THRUST 1 SET
4. BAR ASSY, ADJUSTABLE 2
REFER TO ‘CLAMPING PADS’ FOR OPTIONS
5. BAR ASSY, FIXED 2
REFER TO ‘CLAMPING PADS’ FOR OPTIONS
6. 28-0057 SEAL, FELT 28”
(71 cm)
7. 28-0057 SEAL, FELT 35”
(89 cm)
8. 29-0129 BEARING, MAIN 1 SET
9. 32-00234 PIN, ROLL, 1/8 DIA X 1/2 2
10. 32-0209 PIN, ALIGNMENT, 5/16 DIA X 5/8 8
11. 33-0012 SCREW, CAP, #6-32 X 3/8 8
12. 33-0029 SCREW, CAP, 10-24 X 5/8 14
13. 33-0042 SCREW, CAP, 1/4-20 X 1 8
14. 33-0109 SCREW, CAP, 1/2-13 X 2 2
15. 33-0928 SCREW, SET, 1/4-20 X 3/8, HDOG 2
16. 33-1261 SCREW, SET, 3/8-24 X 3/4, HDOG 16
17. 33-1263 SCREW, SPLITLINE, 1/4-20 X 3 2
18. 39-0201 GEAR, HEADSTOCK 1 SET
NOT SHOWN:
05-1076 SHIPPING KIT, 600SB 1
36-0004 WRENCH, L, 7/64, HEX 1
36-0003 WRENCH, L, 3/32” HEX 1
36-0005 WRENCH, L, 1/8” HEX 1
36-0007 WRENCH, L, 5/32” HEX 1
36-0008 WRENCH, L, 3/16” HEX 1
36-0009 WRENCH, L, 7/32” HEX 1
36-0010 WRENCH, L, 1/4” HEX 1
36-0011 WRENCH, L, 5/16” HEX 1
36-0012 WRENCH, L, 3/8” HEX 1
36-0018 WRENCH, T, 1/8” HEX 1
36-0021 WRENCH, T, 3/16” HEX 1
36-0051 WRENCH, SPANNER 1
32-0084 PIN, DOWEL, 5/32 DIA X 13/16 3
86-0059 CASE, CUSTOM CARRYING, 606SB 1
