DRIVE GEAR AND MAIN GEAR LUBRICATION
Remove the Drive Housing.
Inspect both Drive and Main Gears for chips or burrs and clean as required.
Coat the teeth of the Drive Gear and the Main Gear with a grease approved by
Tri Tool Inc. (See Lubricant Recommendations).
TOOL BLOCK MAINTENANCE.
Clean the Slide Rails, the Feed Nut, the Sprocket Assy and the Feed Screw.
Inspect these parts for damage and replace as required.
Lubricate and reassemble the Tool Block.
Use lubricant on the Feed Screw sparingly or wipe to a film condition.
Excess lubricant will collect grit and/or chips and tend to cause a thread jamming
and/or damage.
Adjust the Adjustable Slide Rail to provide a firm, but not excessive rotational
pressure on the Sprocket.
The Slide Rails must be over tightened to squeeze the oil into a thin film against the
male and female surfaces of the Slide Rails.
Reset for proper operation.
If the Mounting Bracket was overstressed, the Slide Rails may appear to
loosen when mounted if they were adjusted off of the Clamshell.
Adjustment when mounted provides the most satisfactory results.
TOOL HOLDER ADJUSTMENT
Loosen the Hold-down Screws on the Adjustable Slide Rail.
Run the Tool Holder to the most outward position.
Using the Adjustment Set Screws, apply a light force to the side of the Adjustable
Slide Rail so that it is in positive contact with the Tool Holder.
Only adjust the screws that are directly in line with the Tool Holder.
