TASCAM DR-V1HD
25
2 – Names and Functions of Parts
3 Digital zoom indicator
Shows the current digital zoom level. Nothing is shown when zoom is
not in use.
Example:
: Current digital zoom magnification is 1.2 times normal
4 White balance setting
The icon shows the current white balance setting.
Icon Setting Description
AUTO (default) Adjusts automatically according to the situation
BLUB LIGHT Use for white bulb lighting
FL LIGHT Use for daytime white fluorescent lighting
STAGE LIGHT Use for stage and similar lighting
SUNLIGHT Use outdoors in clear weather
CLOUDY Use outdoors in cloudy weather
5 Power supply status
This icon shows the power supply status. See “5 Power supply status” on
page 19 for details.
6 Self-timer function status
Shows whether or not the self-timer is ON. An icon appears when ON.
No indicator : Self-timer function OFF
: Self-timer function ON (set 2 seconds)
: Self-timer function ON (set 10 seconds)
7 F1( ) button function
This shows the function currently assigned to the F1( ) button.
SELF TIMER : Cycles through the self-timer settings.
OFF 2Sec 10Sec
Menu structure
Press the MENU button to open the MENU screen.
The menu contains the following items.
Menu item Function Reference
INPUT Input settings Page 38
REC OPTION
Recording (video/audio) mode
settings
Page 46, 48, 49, 50
PLAY
Playback area, repeat playback and
other settings
Page 62, 69, 70, 75
PB CONTROL Playback speed change and other
special playback
Page 72, 73
REC QUALITY Recording (video/audio) quality
settings
Page 36
SETUP System settings
Page 31, 79, 81, 82,
83, 84
PLAYLIST Playlist editing Page 61, 65
BROWSE
microSD card file and folder
operations
Page 56
