95
Accessories
(for 10-300/15-493 Booms)
BOOM WIRING PARTS LIST
PART# DESCRIPTION QUANTITY
8853 Female Spade Connectors 2
15-472 Switch Boot 2
11-158 Linear Actuator with 4" stroke 2
16-755 Switch 2
16-810 Wiring Harness (for Spray Star 1600) 1
33-190 Wiring Harness (for Spray Star 3000) 1
22-075 Nylon Tie 10
33-272 Fuse 20 amp 1
Use Dielectric Grease On All Electrical Connections
NOZZLE ASSEMBLY PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 16-920-01 Screw 2
2* 16-920-02 Upper Clamp 1
3* 16-920-03 O-Ring 1
4* 16-920-04 Body with Lower Clamp 1
5* 16-920-05 Diaphragm Teflon (Optional) 1
6* 16-920-06 Diaphragm EPDM Rubber (Standard) 1
* 16-920-07 Diaphragm Viton (Optional) 1
7* 16-798 Chemsaver End Cap 1
8 16-800 Gasket Viton 1
9 16-921 Cap 1
10 16-805 Raindrop Tip 1 /
4
RA8 1
* 16-920 Body 1
When the 16-920-05 Teflon Diaphragm is used, it is placed in the assembly in front of the
16-920-06 EPDM Rubber Diaphragm. Nozzles are located 20" (51cm) apart on the right, left,
and center tubes (15-562, 16-927 and 16-928). There are predrilled holes in all tubes. The
Nozzle should be at a 45° angle to the ground for proper application. 9 Nozzles are used on
the 10-300 and 15-493 15' Booms. 11 nozzles are used on the 10-301 18' Boom.
For all 18' Booms: The eleven 16-920 bodies are installed on the boom sections. The
eleven 16-800 viton gasket, 16-805 Raindrop tip and 16-921 cap are in the small parts bag.
For all 15' Booms: The nine 16-920 bodies are installed on the boom sections. The nine
16-800 viton gasket, 16-805 Raindrop tip and 16-921 cap are in the small parts bag.
