15
Diagrams
HYDRAULIC DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 14-352 Hydraulic Hose 54" 1
2 14-351 Hydraulic Hose 46" 1
3 50-456 Hydraulic Cylinder 1 1 /
2
x 7 1
14-267 Seal Kit
4 18-171 11 /
16
x 9 /
16
90° Straight Thread Elbow 3
5 14-355 Hydraulic Hose 81" 1
6 14-354 Hydraulic Hose 84" 1
7 18-306 11 /
16
x 9 /
16
Straight Thread Connector 5
8 15-315 Hydraulic Power Unit 1
15-315-01 Repair Kit
9 27-059 Filler Breather (part of 15-315) 1
18-314 3 /
8
Pipe Coupler 1
18-287 3 /
8
Pipe Nipple x 2 1
10 HBM-6-16 Metric Bolt M6 - 1 x 16 4
HWLM-6 Lockwasher M6 4
11 15-301 Orbitor 1
15-301-01 Seal Kit
12 18-309 Swivel Nut 1
FITTING TORQUE CHARTS
Over tightened fittings will result in crushing the cone which will create a leak.
Charts Developed by Parker Henniphin
Port Side
in. lbs. ft. lbs. ft. lbs.
4 9 /
16
- 18 220 18 15
6 11 /
16
- 16 360 30 35
8 13 /
16
- 16 480 40 60
10 1-14 60 100
12 1 3 /
16
- 12 85 135
14 1 5 /
16
- 12 95 175
16 1 7 /
16
- 12 110 200
20 1 11 /
16
- 12 140 250
24 2 - 12 180 305
32 2 1 /
2
- 12 360 375
Tube Side
Fitting
Size
SAE Tube
Thread
Size
Seal-Lok Straight and Adjustable Fitting
(Steel)Torque Ratings
