17
Diagrams
WIRING DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 34-146 Panel Mounted Circuit Breaker 1
34-145 Circuit Breaker Boot 1
2 8935 Buss Bar (-) 1
3 13-288 Ignition Switch (Kohler 25 099 04)(part of engine) 1
76-310 Key Set 1
4 16-882 Speedometer 1
8854 Fork Terminal 2
8962 Heat Shrink 2
5 14-332 Speedometer Ground Wire 1
6 16-883 Magnetic Sensor 1
7 14-333 Speedometer B+ Wire 1
8 8935 Buss Bar(+) 1
9 14-331 Hour / Voltmeter Ground Wire 1
10 42-064 Hour / Voltmeter Combo 1
11 14-330 Hour / Voltmeter B+ Wire 1
12 Oil Sender (part of engine)
13 Ignition Module (part of engine)
14 Fuel Shut-Off Solenoid (part of engine)
15 Rectifier (part of engine)
16 Starter (part of engine)
17 50-323 Red Battery Cable 1
18 33-216 Battery (optional) 1
19 22-054 Ground Battery Cable 1
20 15-484 Wire Assembly Fuse Block To + Bat. (on solenoid) 1
21 15-485 Wire Assembly Fuse Block To Ground 1
22 33-271 Fuse Block 1
23 Wire With Fuse (part of engine)
Fuse AGC 30
24 22-002 Interlock Switch 1
25 14-334 Ignition Switch Ground Wire 1
26 33-480 Pressure Switch 1
27 16-989 Hypro Pump With Electric Clutch 1
8958 Male Slide on Terminal 1
8962 Heat Shrink 3 /
16
1
28 15-457 Ground Wire 1
29 77-207 Buzzer 1
8849-3 Black Wire 1
8860 String Connector 1
8859 Ring Terminal 3 /
16
1
8853 Slide On Connector 1
8962 Heat Shrink 2
8963 Heat Shrink 1
30 14-335 Spray Pump Switch B+ Wire 1
31 15-314 Toggle Switch 1
15-472 Switch Boot 1
32 50-359 Oil Warning Light 1
8850-12 Red Wire 1
8860 String Connector 1
8859 Ring Terminal 3 /
16
1
8958 Male Slide On Terminal 1
8962 Heat Shrink 3 /
16
2
8963 Heat Shrink ¼ 1
N.S. 22-017 Cable Black (transmission to frame) 1
14-336 Main Wire Harness (Includes all wire colors with *) 1
