71
Accessories
CONTROL 1607P SYSTEM PART LIST
REF# PART# DESCRIPTION QUANTITY
1* 16-985 Computer Console (Only) 1
16-234 Computer Cover 1
2* 10-286 Direct Wiring Cable 1
3 14-370 Drive Line (Spray Star 1600P) 1
4* 15-528-01 Speed Sensor 1
5* 15-515 Flow Meter 1
6 33-271 Fuse Block 1
7 33-508 Auto Blade Type Fuse 15Amp 1
33-284 Auto Blade Type Fuse 5 Amp 1
8 14-348 Solenoid Valve 1
9* 16-986 Pressure Regulating Valve 1
10 33-271 Fuse Block 1
11 33-508 Auto Blade Type Fuse, 5 Amp 1
12* 14-348 Solenoid Valve 1
13* 16-986 Pressure Regulating Valve 1
14 16-992 Red Jumper Wire 1
15 16-991 Black Jumper Wire 1
* 16-984 844 Sprayer Control Kit (includes all * items)
Use Dielectric Grease On All Electrical Connections
To reset circuit breaker on ball valve, you must disconnect power to the computer.
15-515 FLOW METER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 15-515-02 Nylon Ring Nut 2
2* 15-515-03 Nylon Hose Barb 2
3* 15-515-04 Viton O-ring 2
4 15-515-05 Flow Meter Body 1
5 15-515-06 Turbine Insert Assembly 1
6 15-515-07 Flow Meter Pickup 1
* 15-515-01 Hose Barb Assembly
