127
Accessories
10-106 FRESH WATER WASH TANK PARTS LIST
TO BE USED WITH 1610P
REF# PART# DESCRIPTION QUANTITY
1 HB-516-18-075 Bolt 5 /
16
- 18 x 3 /
4
4
HWL-516 Lock Washer 5 /
16
4
HW-516 Washer 5 /
16
4
2 10-216 Fresh Water Tank Bracket 1
3 HB-38-16-200 Bolt 3 /
8
-16 x 2 2
HNTL-38-16 Lock Nut 3 /
8
-16 2
4 10-234 3 Gallon Rectangular Tank 1
5 16-158 Close Nipple 3 /
4
x 3 /
4
1
6 16-960 Spigot 3 /
4
NPT 1
7 16-151 Elbow FPT 3 /
4
x 3 /
4
1
INSTALLATION INSTRUCTIONS
1. Fresh Water Wash Tank mounts on the right side of the machine.
2. Insert the close nipple into the bottom of the tank. Then place the elbow on the close nipple so it is
pointing away from the machine. Place the spigot into the elbow. For best results use plumbers tape on
all fittings.
3. Place the mount bracket onto the right side panel using the two 3 /
8
bolts and lock nuts.
4. Line holes on the tank with holes on the mount bracket and use the 5 /
16
bolts to fasten tank to mount
bracket.
5. Rinse tank with clear water and check for leaks around fittings.
This tank is for fresh clear water ONLY. Do not put chemicals in this tank.
