16-524 AND 16-866 MOTORIZED CONTROL VALVE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 16-870 Valve Cover 1
2* 16-524-01 #6 Self Tapping Screw 3 /
4
" Long 6
3 16-897 Seal Tetraseal 1
4* 16-875 Motor Assembly (For 16-524 on 1602P) 1
4* 16-866-01 Motor Assembly (For 16-866 on 1604P) 1
5* 16-957 Woodruff Key 1
6 16-524-04 Isolation Flange Assembly 1
7 16-524-02 Coupler Shaft 1
8* 16-956 Butterfly 1
9* 16-524-03 Valve Body Mod. 1
* 16-524-05 1" Valve ISO-Body Kit
WHEN SERVICING VALVE:
Replace valve body with iso-body kit (16-524-05) if valve has been leaking internally.
Replace motor assembly if the motor will not run or if the printed circuit board is corroded.
Before reassembling valve, remove the coupler shaft from the valve body. Apply Loctite to coupler shaft and
woodruff key. Place the coupler shaft (Ref# 7) and the woodruff key (Ref# 5) onto the motor shaft. Plug motor
into the valve connector coming from Sprayer Control Console. Check that the motor rotates in both directions.
Motor must stop when coupler cam releases printed circuit board switch button.
When reassembling valve, grease both sealing surfaces of coupler shaft. Insert coupler shaft into Iso-flange and
be sure seal properly seats on shaft. Install on valve body and apply RTV 738 to mounting holes. Reassemble
remaining items as shown in parts diagram on opposite side.
16-456 FLOW METER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 16-456-03 O-Ring Viton 2
2* 16-456-04 RFM55 dual O-Ring XDCR assembly 1
3 16-456-05 RFM55 turbine 1
4 16-456-06 Turbine hub/bearing assembly 1
5 16-143 Turbine stud assembly 1
6 16-456-01 Sensor housing 1
7 16-456-02 #10-32 x 3 /
4
stainless steel screw 12
8 16-144 O-Ring Viton 1
9 16-456-07 Hub housing with inserts 1
16-456-08 Mounting bracket RFM 55 1
16-456-09 Thread sealer 1
* 16-456-10 O-Ring Transducer Kit
