113
Accessories
COMPRESSOR AND CONTROL BOX PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* HN-14-20 Nut 1 /
4
- 20 4
2 15-524 Foamer Bracket 1
3* 15-504 Compressor 1
4* 15-506 Switch Box 1
15-506-01 Fuse (F10A 250V) 1
15-506-02 Switch 1
5 HB-14-20-100 Bolt 1 /
4
- 20 x 1 2
HW-14 Washer 1 /
4
2
HWL-14 Lockwasher 1 /
4
2
HN-14-20 Nut 1 /
4
- 20 2
6 15-525 Switch Box Mount 1
7* Wing Nut 2
8 HB-14-20-100 Bolt 1 /
4
- 20 x 1 1
HW-14 Washer 1 /
4
1
HWL-14 Lockwasher 1 /
4
1
* 15-500 Foamer 1
INSTALLATION INSTRUCTIONS
Safety: Before working on machine stop engine, set park brake, remove key from ignition and block
wheels. Disconnect negative (-) battery terminal.
1. Remove original mounting bracket, if one was provided, from bottom of compressor and discard. Place
compressor (Ref 3) on mounting bracket (Ref 2), with controls facing the front. Finger tighten a nylon
lock nut (Ref 1) on each of the two bolts closest to the side panel.
2. Place mounting bracket (Ref 2) onto side panel as shown. Hole (B) is threaded. Insert one 1 /
4
- 20 x 1 bolt
with lockwasher and washer (Ref 8) into hole (B). Insert the other two 1 /
4
- 20 x 1 bolts and washers (Ref
5) into hole (A) with lockwasher and nut on the inside panel.
3. Place switch box mount (Ref 6) on bolts furthest from side panel. Place one nylon lock nut (Ref 1) on
each of the two bolts. Tighten all four nuts on compressor bottom.
4. Place control box (Ref 4) on control bracket and tighten wing nut (Ref 7).
5. Connect the large plastic electrical plugs on compressor and control box
