Accessories
14-311 HOSE REEL PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-38-16-350 Bolt 3 /
8
- 16 x 3 1 /
2
2
HNTL-38-16 Lock Nut 3 /
8
- 16 2
2 14-325 Boom Carrier (part of machine) 2
3 10-221 Hose Reel Mount 1
4 16-906 Electric Hose Reel 1
16-129 Manual Hose Reel 1
5 18-249 Brass Fitting 3 /
4
MPT x 3 /
4
HB 1
6 HB-516-18-150 Bolt 5 /
16
- 18 x 1 1 /
2
4
HNTL-516-18 Lock Nut 5 /
16
- 18 4
7 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HNTL-38-16 Lock Nut 3 /
8
- 16 2
8 16-158 Close Nipple 3 /
4
2
9 16-151 Elbow F.P.T. 3 /
4
x 3 /
4
1
10 16-859 Ball Valve 3 /
4
Brass 1
11 16-154 Fitting 3 /
4
MPT x 3 /
4
HB 1
12 8887-90 Orange PVC Hose 3 /
4
1
18-040 Hose Clamp 2
13 18-260 Bushing 1 1 /
4
x 3 /
4
1
14 18-073 Pipe Nipple 3 /
4
1
INSTALLATION INSTRUCTIONS
1. Wear protective clothing when draining the tank and taking apart the lines.
2. Drain tank and spray system in a safe and approved method insuring that no chemical or water remain in
tank as you will be taking apart lines.
3. Remove key from ignition, set park brake and block wheels.
4. Remove square rubber covers on boom carriers.
5. Place hose reel bracket inside the boom carrier tube on left side and outside on right side with arms
pointing toward front of machine.
6. Lower bracket until top hole in bracket lines up with hole in upright. Bolt as shown.
7. Put hose reel on hose reel bracket with fitting on left side of machine. Use four bolts 5 /
16
- 18 x 1 1 /
2
and
four 5 /
16
- 18 lock nuts to hold in place. Tighten bolts.
8. Put 18-249 barb fitting into hose reels side.
9. Use 8887- 90 hose to connect reel to ball valve, clamp with 18-040 hose clamps.
10. Use 22-075 nylon ties to tie hose to main feed hose.
11. For 1610P: Remove pipe plug "D." Insert the bushing, pipe nipple, and ball valve. Place the hose barb
fitting into the ball valve and connect the hose. See Figure 3.
12. For 1602P and 1607P: Remove hose from elbow on throttling valve. Remove throttling valve, gauge and
elbow. Re-assemble as shown in Figure 1, using parts "C". Assemble throttling valve with gauge and
elbow into top of tee and reconnect the hose.
135. For 1604P: Remove hex plug from "A" and assemble as shown in Figure 2.
(Continued on next page)
