123
Accessories
15-511 FOAM NOZZLE SUB ASSEMBLY PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1† Nut 1
2† Screw 1
3† Foam Nozzle Inlet Body 1
15-510-01 Nozzle Mounting Rods 2
4*† 15-511-02 Foam Sponge 1
5*† Stainless Steel Screen 1
6*† 15-511-04 Stainless Steel Snap Ring 1
7 18-123 Hose Clamp 2
8 Drop Tube 1
9 15-511-05 Restrictor Bell 1
† 15-511-01 Foam Nozzle Inlet Sub Assembly
* 15-511-06 Foam Kit (includes 2 each * items)
When using the Star Shield you will need to leave the drop tube (Ref 8) the full
length. For all other booms the drop tube will need to be shortened to half its length.
