Operating Instructions
Primetest 220
24
9.9 Spare Parts.
Fuse 31.75mm x 6.35mm 12.5A 250V Type T Seaward Part No: 27B111
Test Leads (with alligator clips)
Seaward Part No: 44B124
Carry Case Seaward Part No: 71G082
Appendix 1
PrimeTest 220 Diagnostic Indications
Mains Supply Icons
PE PN NE
The mains supply is too high, too low or not present.
Flash Flash Off
These icons can also indicate a fault on RLY2.
Flash On Flash Earth Open - Circuit
On Flash Flash Neutral Open - Circuit
Err 1
The PrimeTest 220 has failed one of the Earth Relay Pre-
Check tests. Contact your local service agent.
Err 2
The PrimeTest 220 has failed one of the Safety Relay Pre-
Check tests. Contact your local service agent.
Err 3
The PrimeTest 220 has failed an Internal Relay Pre-
Check test. Contact your local service agent.
Err 4
Preload safety test has failed. EUT load too high.
Err 5
The PrimeTest 220 has failed an Internal Relay Pre-
Check test. Contact your local service agent.
