USB-1602HS-2AO User's Guide Installing the USB-1602HS-2AO
10
CA-68-3R (3-feet) CA-68-3S (3-feet) CA-68-6S (6-feet)
Screw termination board with screw terminals
 TB-102
Additional documentation
In addition to this hardware user's guide, you should also receive the Quick Start Guide (available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf ). This booklet supplies a brief description of
the software you received with your USB-1602HS-2AO and information regarding installation of that software.
Please read this booklet completely before installing any software or hardware.
Signal conditioning accessories
MCC provides signal termination products for use with the USB-1602HS-2AO. Refer to the "Field wiring and
signal termination" section for a complete list of compatible accessory products.
Unpacking the USB-1602HS-2AO
As with any electronic device, take care while handling to avoid damage from static electricity. Before
removing the USB-1602HS-2AO from its packaging, ground yourself using a wrist strap or by simply touching
the computer chassis or other grounded object to eliminate any stored static charge.
If the USB-1602HS-2AO is damaged, notify Measurement Computing Corporation immediately by phone, fax,
or e-mail.
 Phone: 508-946-5100 and follow the instructions for reaching Tech Support.
 Fax: 508-946-9500 to the attention of Tech Support
 Email:
[email protected]
For international customers, contact the local distributor where you purchased the USB-1602HS-2AO. Click on
this link
www.measurementcomputing.com/sales.asp to locate your distributor.
