DeviceNet Slave Communication Module DVPDT02-H2
DVP-PLC Application Manual 25
Attribute
ID
Access
rule
Name Range Default Explanation
Unit: byte
3 Get Connection path N/A N/A
Polling path of the parameter
value.
Max. connection path: 255 bytes
4 Get Descriptor 0 ~ 127 N/A The descriptor of parameter
5 Get Data type 1 ~ 8 N/A The code of data type
6 Get Data length N/A N/A
Number of bytes occupied by the
parameter value (Attribute 1).
Unit: byte
Instance 3: Node address
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get Parameter value 0 ~ 63 N/A Node address of DVPDT02-H2
2 Get
Length of
connection path
N/A N/A
The length of connection path
(Attribute 3). “0” refers to the
connection path is not designated.
Unit: byte
3 Get Connection path N/A N/A
Polling path of the parameter
value.
Max. connection path: 255 bytes
4 Get Descriptor 0 ~ 127 N/A The descriptor of parameter
5 Get Data type 1 ~ 8 N/A The code of data type
6 Get Data length N/A N/A
Number of bytes occupied by the
parameter value (Attribute 1).
Unit: byte
Instance 4: Serial transmission speed
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get Parameter value 0 ~ 2 0
Communication speed of
DVPDT02-H2
2 Get
Length of
connection path
N/A N/A
The length of connection path
(Attribute 3). “0” refers to the
connection path is not designated.
Unit: byte
3 Get Connection path N/A N/A
Polling path of the parameter
value.
Max. connection path: 255 bytes
4 Get Descriptor 0 ~ 127 N/A The descriptor of parameter
5 Get Data type 1 ~ 8 N/A The code of data type
6 Get Data length N/A N/A
Number of bytes occupied by the
parameter value (Attribute 1).
Unit: byte
Instance 5: Length of input I/O data
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get/Set Parameter value 0 ~ 200 32 Unit: byte
