DeviceNet Slave Communication Module DVPDT02-H2
DVP-PLC Application Manual 23
Attribute ID Access rule Name Data type
7 Get BaudRateSwitchChanged BOOL
8 Get MACIDSwitchValue USINT
9 Get BaudRateSwitchValue USINT
Common services
Implemented for
Service code
Class Instance
Service name
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x4B No Yes Allocate_Master/Slave_Connection_Set
0x4C No Yes Release_Master/Slave_Connection_Set
„ Class 0x05 – Connection object
Class attribute
Attribute ID Access rule Name Data type
1 Get Revision UINT
Instance 1: Explicit message connection
Attribute ID Access rule Name Data type
1 Get State USINT
2 Get InstanceType USINT
3 Get TransportClassTrigger USINT
4 Get ProducedConnectionId UINT
5 Get ConsumedConnectionId UINT
6 Get InitialCommCharacterisitcs BYTE
7 Get ProducedConnectionSize UINT
8 Get ConsumedConnectionSize UINT
9 Get/Set ExpectedPackedRate UINT
12 Get/Set WatcdogTimeoutAction USINT
13 Get
Produced Connection Path
Length
USINT
14 Get Produced Connection Path EPATH
15 Get
Consumed Connection Patch
Length
USINT
16 Get Consumed Connection Path EPATH
Instance 2: Polled I/O connection
Attribute ID Acccess rule Name Data type
1 Get State USINT
2 Get InstanceType USINT
3 Get TransportClassTrigger USINT
4 Get ProducedConnectionId UINT
5 Get ConsumedConnectionId UINT
6 Get InitialCommCharacteristics BYTE
7 Get ProducedConnectionSize UINT
