DeviceNet Slave Communication Module DVPDT02-H2
DVP-PLC Application Manual 24
8 Get ConsumedConnectionSize UINT
9 Get/Set ExpectedPackedRate UINT
12 Get/Set WatchdogTimeoutAction USINT
13 Get
Produced Connection Path
Length
USINT
14 Get Produced Connection Path EPATH
15 Get
Consumed Connection Path
Length
USINT
16 Get Consumed Connection Path EPATH
Common services
Implemented for
Service code
Class Instance
Service name
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Appendix B: DeviceNet Ojects Defined by DVPDT02-H2
„ Class 0x95 – DVPDT02-H2 I/O data configuration object
Class attribute
Attribute ID Access rule Name Data type
1 Get Revision UINT
Instance 1: Model code
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get Parameter value 560 560
Model code of DVPDT02-H2: 560 (
H’0230)
2 Get
Length of
connection path
N/A N/A
The length of connection path
(Attribute 3). “0” refers to the
connection path is not designated.
Unit: byte
3 Get Connection path N/A N/A
Polling path of the parameter
value.
Max. connection path: 255 bytes
4 Get Descriptor 0 ~ 127 N/A The descriptor of parameter
5 Get Data type 1 ~ 8 N/A The code of data type
6 Get Data length N/A N/A
Number of bytes occupied by the
parameter value (Attribute 1).
Unit: byte
Instance 2: Firmware version
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get Parameter value 0 ~ 65,535 N/A Firmware version of DVPDT02-H2
2 Get
Length of
connection path
N/A N/A
The length of connection path
(Attribute 3). “0” refers to the
connection path is not designated.
