DeviceNet Slave Communication Module DVPDT02-H2
DVP-PLC Application Manual 22
Attribute ID Access rule Name Data type
MaxRev
MinRev
USINT
USINT
5 Get Status WORD
6 Get Sn UDINT
7 Get
ProdName
StrLen
ASCIIStr
USINT
STRING
Common services
Implemented for
Service code
Class Instance
Service name
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
„ Class 0x02 – Message router object
Class attribute
Attribute ID Access rule Name Data type
1 Get Revision UINT
6 Get MaxIdClass UINT
7 Get MaxIdInstance UINT
Instance
Attribute ID Access rule Name Data type
2 Get NumAvailable UINT
3 Get NumActive UINT
Common services
Implemented for
Service code
Class Instance
Service name
0x0E Yes Yes Get_Attribute_Single
„ Class 0x03 – DeviceNet object
Class attribute
Attribute ID Access rule Name Data type
1 Get Revision UINT
Instance attribute
Attribute ID Access rule Name Data type
1 Get MACID USINT
2 Get BaudRate USINT
3 Get/Set BusofInterrupt BOOL
4 Get/Set BusofCounter USINT
5 Get
AllocationInfo
AllocationChoice
MasterNodeAddress
BYTE
USINT
6 Get MACIDSwitchChanged BOOL
