Harken 1093 Carbon Jib Reefing & Furling - Manual (Page 8)

ASSEMBLY
Remove plastic clip from Hysol® adhesive pack.
1) Mix for five minutes in bag.
2) Pour entire contents into cup.
3) Squeegee remaining epoxy into cup.
4) Continue to thoroughly stir epoxy in cup.
Use glue brush to coat the inside of the foil for one or two
inches. Coat 1/2 of the outside of the connector with epoxy
and slowly insert the connector into the foil. Work the con-
nector in and out as you insert it to adhere the epoxy without
dry spots on the inside of the foil. As excess epoxy comes off
the connector, clean it up using the acid brush. Use excess
to coat feeder area of connector. Clean up the end of the foil
using paper towel wetted with acetone taking care that no
epoxy is in the sail grooves.
8 2/2.5 Carbon Furler May 2002
Adhesive Alert
You must follow four-step
mixing instructions shown
below exactly or the foil
connector bond will fail.
Surfaces must be dry.
Temperature should be higher than 60°F (15°C).
If you glue at a lower temperature:
50°F (10°C) minimum
gently warm joints with a hair dryer to no more than:
100°F (38°C), a temperature at which you can still
hold the foil comfortably in your hand.
If glued in temperature less than 60°F (15°C, allow glued
foils to cure undisturbed for 48-hours before moving.
Adhesive Working Times:
75°F (24°C) - 1 hour
85°F (29°C) - 45 minutes
Allow glued foils to cure undisturbed for 24-hours
Cool Weather
Warm Weather
