Harken 1093 Carbon Jib Reefing & Furling User Manual
Page 2
2
2/2.5 Carbon Furler
December 2001
TABLE OF CONTENTS
Parts
3
Pictures and list of all parts
Specifications
4
Rod sizes
Clevis pin sizes
Luff tape sizes
Rigging, attachment to lower unit
Retrofits, fitting rod
Tools required
Supplies for gluing foils
Alignment splints
Headstay length
Preparation for Assembly
5-6
Foil cut length
Top foil cut length
If you have a short top foil
Cutting top foil
Assembly
7-11
Sliding foils onto rod
Attaching feeder
Joining foils using connectors
Preparing foil for gluing
Gluing foils using Hysol® adhesive
Gluing feeder
Aligning joined foils
Sliding halyard swivel onto foils
Capping foils with trim cap
Removing splint
Installing Navtec® eye
Installing carbon furling unit
Assembling turnbuckle
Foil height
Commissioning
12-16
Tying soft attachment lines
Halyard wraps
Prevent halyard wraps
Pendants
Halyard restrainer
Halyard tension
Warranty
Warranty of Harken Carbon parts is
one year from the time of purchase.
