June 2002 2/2.5 Carbon Furler 7
ASSEMBLY
Assuming that installation is done from the top, slide
bottom foil onto rod so end with holes is at bottom
end of foil.
Slide feeder over so, so rounded sail groove corners will be at
the bottom end of foil.
Slide full-length 72" (1.83m) foils onto the rod.
Assemble connectors onto rod in preparation for glueing.
Place one bushing half in socket on either side of connector,
grooved side up. Bring connector up on rod and place other
bushing half on rod and rotate bushing so seam is at top
and bushing assembly stays in place.
Place foil on bench with grooves facing up and supported on
wood blocks.
