Gasboy Fuel Point Ground Antenna User Manual
Ground antenna installation instructions, Fuel point, System
Table of contents
Document Outline
- Table of Contents
- 1 - Introduction
- 2 - Component Overview
- 3 - Installation
- Important Vehicle Parameters - Read Before Proceeding
- Installing A Fuel Point Ground Antenna For Fueling
- C09822 Junction Box
- C09716 Antenna Sealant
- For Installing a Direct Buried and Sealed Antenna
- 1 Saw a 3/16 inch x 1 inch deep slot that will be used to route the antenna lead into the Fuel Point amplifier.
- 2 At the island, chisel in a second recess to allow drilling a º inch diameter hole starting below the pavement and at an angle into the base of the pump.
- 3 After machining the pavement, flush the recesses and slots free of debris.
- 4 Add dry sand and tamp to fill the antenna recess, leaving a 1 inch deep recess.
- 5 Route lead-in cable supplied from the antenna recess to the FP Amplifier mounted in the base of the pumps and wire to antenna with butt connectors supplied.
- 6 Mix ¹ gallon of sealant with hardener according to instructions on the container and seal the antenna and lead-in slot. Sealant should be used only in the top º inch of the installation.
- For Installing a Direct Buried and Sealed Antenna
- C07364 Surface Mount Antenna Installation
- 1 Locate the antenna housing with the nozzle and mark pavement and housing outline on the side of the island.
- 2 Drill a º inch diameter hole (within the housing outline and not more than 1-1/2 inch above pavement) into the base of the pump.
- 3 Attach the C07362 antenna in the recess on the bottom of housing. Attach cable using butt connectors supplied and route and clamp cable in machined slot.
- 4 Attach metal wire chamber bracket to the island end of the housing using the self threading screws supplied.
- 5 Slide housing bracket against island. Drill all mounting holes. Install threaded inserts and attach housing to ground.
- Ground Antenna Used for Gate Control
