Installation of the 9800A/2600A Pump Interface Kit
Page 6
MDE-4863 Gasboy® 9800A or 2600A Pump Interface Kits Installation Instructions · October 2009
4
Loosen and remove (if necessary) the two screws located on the left and right door support
brackets and pivot the Display Panel down.
Figure 3: Removing the Screws on the Front Panel
Screws
5
Pull the connector off P1on the Power Supply. After a few seconds, reconnect P1 (see
).
Figure 4: Power Supply
P1
