Gasboy Submersible Drv Relay Kit User Manual
Introduction, Intended users, Single and dual relay kits
Table of contents
Document Outline
- Introduction
- Important Safety Information
- Installing the Atlas Submersible Drive Relay Kit
- Preparing for the Installation
- Installing the Atlas Submersible Drive Relay Kits
- 1 Unlock and remove the front panel.
- 2 Remove the two screws securing the bezel assembly and remove the assembly.
- 3 Remove the two screws securing the display panel and pivot display panel down. The unit will swing forward and down after screws are removed.
- 4 Pull the connector off P1 on the power supply. After a few seconds, reconnect P1.
- 5 Attach the relay module to the platform base using M4 screws.
- 6 Attach the relay cable to P7 of the display CPU board.
- 7 Locate the 14 gauge red and blue wires coming from the AC conduit under the platform (marked K1-1 and K1-2 respectively). Dual dispensers will also use the 14-gauge orange and black wires (marked K2-1 and K2-2 respectively).
- 8 Attach the red wire to screw terminal #1 and the blue wire to screw terminal #2 of relay #1. Attach the orange wire to screw terminal #1 and the black wire to screw terminal #2 of relay #2.
- 9 Complete the wiring between the breaker panel, pump and AC J-Box as shown in FE357B Atlas Pump Retail/Commercial Field Wiring Diagram.
- Completing the Installation
- 1 Reassemble the pump (fasten the display panel in place, install and secure the bezel assembly, and install and lock the front panel).
- 2 Inform the manager/owner that the circuit breakers for MICRO, LIGHTS and FEED will be turned on and then turn them on.
- 3 Remove the lockout/tagout and return to normal operation.
