Fluke Biomedical 190M - Manual (Page 121)

Specifications
Oscilloscope
8
111
Table 2. Record Lenth (Samples/points per input)
Mode Glitch Detect On Glitch Detect Off Max. Sample Rate
Scope - Normal 300 min/max pairs 3k true samples compressed into
1 screen (300 samples per screen) 190M-24: 2.5 GS/s (1 or 2 channels
on)
190M-4: 1.25 GS/s (3 or 4
channels on)
Scope - Fast 300 min/max pairs
Scope - Full 300 min/max pairs 10k true samples, compressed into
1 screen.
Use Zoom and Scroll to see
waveform details
Scope Record Roll 30k samples 4 x 125 MS/s
Trend Plot >18k min/max/ average values per
measurement Up to 5 measurements per second
Glitch Detection
4
μ
s to 120 s/div ............. displays glitches as fast as 8 ns
Waveform Display............................................. A, B, C, D,
Math (+, -, x, X-Y mode, spectrum)
Normal, Average, Persistence, Reference
Time Base Accuracy ....................... ±(100 ppm + 0.04 div)
Trigger and Delay
Trigger Modes ....... Automatic, Edge, Video, Pulse Width,
N-Cycle, External (190M-2)
Trigger Delay .................................. up to +1200 divisions
Pre Trigger View .............................. one full screen length
Delay ................................................... -12 div to +1200 div
