Integer
Register Attribute Description Notes
40081 RW Reset integer scaler flag. Range 0 to 1. Writing a value of 1 to this
register causes the device to recalculate
the scalers used to calculate the integer
process variables.
40082 RW Start signature function flag. Range 0 to 2.
0 = Function complete
1 = Ramp function
2 = Step function
40083 RW Signature/logger data packet to be read. Range 1 to 650.
40084 RW Load signature data packet into
signature registers. Range 0 to 1. Writing a value of 1 to this
register causes the device to load the
signature registers with the signature
packet requested in register No. 40083.
40085 RW Load logger data packet into signature
registers. Range 0 to 1. Writing a value of 1 to this
register causes the device to load the
signature registers with the logger packet
requested in register No. 40083.
30086 RO Number of signature packets available. Range 0 to 650
30087 RO Number of logger packets available. Range 0 to 650
30088 RO Signature/logger accessory on/off status
register.
40089 RW Variable number for process temperature
input to be used in flow calculation. Range -1 to 1023. Writing a value in the
specified range will cause the device to
use the value from that variable as the
process temperature input to the flow
calculation; -1 disables.
40090 RW Variable number for upstream process
pressure (P
1
) input to be used in flow
calculation.
Range -1 to 1023. Writing a value in the
specified range will cause the device to
use the value from that variable as the
upstream process pressure input to the
flow calculation; -1 disables.
40091 RW Variable number for downstream
process pressure (P
2
) input to be used in
flow calculation.
Range -1 to 1023. Writing a value in the
specified range will cause the device to
use the value from that variable as the
downstream process pressure input to the
flow calculation; -1 disables.
40092 RW Variable number for specific gravity input
to be used in flow calculation. Range -1 to 1023. Writing a value in the
specified range will cause the device to
use the value from that variable as the
specific gravity input to the flow
calculation; -1 disables.
40093 RW Variable number for molecular weight
input to be used in flow calculation. Range -1 to 1023. Writing a value in the
specified range will cause the device to
use the value from that variable as the
molecular weight input to the flow
calculation; -1 disables.
StarPac II User Interface Manual 35
