Override Condition - Indicates the controller is currently not
capable doing any more to achieve the setpoint (or valve
position). This can be any of the trip conditions, or a mechanical
or software travel limit has been reached and the controller has
exceeded the 5 percent current limit.

Sensor Malfunction - One of the sensors has a suspect output.
(See sensor errors for detail.)

Device Malfunction - The electronics has an internal error.
(See device errors for detail.)

System Information - Allows the user to check the factory hardware
configuration for reference or spare parts. The following list shows
the items listed:

Valve Serial Number:

Spring:

Trim Number:

Spring Type:

Trim Characteristic:

Air Action:

Trim Type:

Electronics S/N:

Pressure Class:

EPROM Version:

Valve Model:

Sensor Rating:

Flow Direction:

Sensor Drawing No.:

Body Size:

P1 Serial Number:

Body Material:

P2 Serial Number:

Packing Style:

P1 Calibration Date:

Packing:

P2 Calibration Date:

Gasket Material:

Miscellaneous No. 1:

Actuator Size:

Miscellaneous No. 2:

View

Registers - Allows the user to view any internal

integer or floating point Modbus register using the register

map provided (see appendix for a list of registers). String

registers cannot be viewed with this function.

Tune Menu

The T

UNE

menu is used to view and configure the controller

variables and gains, change modes, and reset the totalizer. The

Com-

mand

Con-

fig

Sta-

tus

Cal-

brat

Set-

pnt

Mode

Tune

Next

Prop

Band

Rset

Rate

Next

Der

Time

Figure 4: Tune Menu Tree

UNE

menu is arranged as shown in Figure 4.

Mode - Has two options for defining the current mode and the
source of the mode.

Scal

Slct

Rset

Totl
